2013-2014 MUSTANG GT TRACK CAL UPDATE

2013-2014 MUSTANG GT TRACK CAL UPDATE
M-14204-MGTTCU
Retail
$135.00
Sold in Units of
Each (1)
Instruction Sheet
Not Available
Sign in to add to wish list

Click to chat

The “Fifty States Street Legal” icon means that this part has been determined by the California Air Resources Board (CARB) not to have an adverse effect on emissions when installed and used properly in the application(s) identified in the product description. Under EPA and CARB policy, such parts may be installed in vehicles driven on public roads and highways.
 For 2013-2014 Mustang GT manual transmission-equipped Mustang GT's who have already installed M-FR1-MGT  or M-9603-MGTB performance calibration.

Track Cal upgrade is a calibration re-flash identical to M-14204-MGTTC Mustang GT Track Cal.

Track Cal is a Ford Performance exclusive calibration that provide added functionality to 2013-2014 Mustang GT's with manual transmission.

The calibration includes these functions:

  • Driver adjustable Launch Control, or "2-step engine speed limiting"
  • Driver adjustable Pit Lane Speed Control
  • Lopey idle
  • Improved engine performance- Up to 60lb-ft at 1500rpm & peak increases of 16 hp and 7 lb-ft on 93 octane fuel

How do TracKey and Track Cal work?

Track Cal contains exclusive calibration features designed for track use and derived from the same software algorithms and features employed in Ford Performance turn-key race cars such as the Boss 302R, Boss 302S, and Cobra Jet.

Engine performance is similar to the calibration available in the Ford Performance M-FR1-MGTB kit and modifies several PCM parameters including:

  • Twin Independent Variable Cam Timing (TiVCT)
  • Engine braking
  • Ignition timing
  • Wide-Open Throttle fueling
  • Accelerator pedal map
  • Idle speed
  • Throttle response

Track Cal for Mustang GT

  • Alter several thousand lines of code and several hundred calibration parameters.
  • Is the only calibration of their type that have gone through the rigorous Ford Performance test procedures.
  • Is a 50 state legal aftermarket engine performance software upgrade for the 2013-2014 Mustang GT with Manual Transmission with CARB EO (D-598-14)




Part Type
Engine: Power Packs
Warranty Availability
Not Available
Packaged Dimensions
14.5" x 10.5" x 0.25
Packaged Weight
0.2 lb(s)
UPC Code
756122003954
Catalog Page Number
49
Country of Origin
Taiwan, Republic of China
