TREMEC TKX-600 5 SPEED TRANSMISSION .81 OVERDRIVE

M-7003-TKX81

Retail

$3,495.00

Sold in Units of

Each (1)

Instruction Sheet

Not Available

This part is in your Wish List

This part has been added to your Wish List

ATTENTION:

This part is intended as a replacement part for use only in the application(s) identified in the product description. Installation of this part in a vehicle for which it is not intended may violate U.S. and Canadian laws and regulations related to motor vehicle emissions.

OVERVIEW
SIMILAR PARTS

Unleash unmatched performance with the TREMEC TKX-600 5 SPEED .81 OVERDRIVE, engineered for 600 lb.-ft. of torque. Experience smoother shifts and ultimate durability—it's the perfect fit for your custom build.

Ford Performance is proud to offer the latest 5 speed manual transmission from Tremec - the TKX. Capable of handling 600 lb.-ft. of torque, it's the perfect 5 speed manual transmission for your custom build.

Reduced overall size - easier to package in a variety of vehicles

Improved, smoother shifting

Hybrid carbon/bronze synchronizers - 7,500 rpm shift capability

Wider, more durable gears than TKO transmission
Caged needle bearings for improved durability

26 spline input shaft / 31 spline output shaft
1st gear = 2.87, 2nd gear = 1.89, 3rd gear = 1.28, 4th gear = 1, 5th gear = .81
Dry weight = 99 lbs.
Fluid capacity 2.7 quarts - Tremec HIgh Performance Manual transmission fluid or Mobil 1 Synthetic ATF recommended
Use M-6392-R58 bellhousing for 302/351 engines
Use M-6392-M46 bellhousing for 4.6/5.0/5.2/5.4 modular engines

Part Type

Driveline: Manual Trans

Warranty Availability

Available

Package Dimensions

17" x 14" x 35"

Package Weight

108.5 lb(s)

UPC Code

756122015506

Country of Origin

Mexico
