5.0L COYOTE CRATE ENGINE AND CONTROLS PACK

This part is no longer available.
5.0L COYOTE CRATE ENGINE AND CONTROLS PACK
M-6007-M50AK
Instruction Sheet
Not Available
WARNING:
This part is designed and intended for competition use only or off-highway use only. It should not be installed on a vehicle that is driven on public roads and highways. Installation of this part on a vehicle driven on public roads and highways is likely to violate U.S. and Canadian laws and regulations relating to motor vehicle emissions.
WARNING: Cancer http://www.p65warnings.ca.gov.
POWER UP YOUR SPRING PROJECT with a 5.0L Coyote Crate Engine and Controls Pack
The Ford Performance all-aluminum 2017 5.0L Coyote crate engine is a modern 5.0L 32-valve DOHC V-8 that uses advanced features like Twin Independent Variable Camshaft Timing (Ti-VCT) to deliver 435 horsepower @ 6500 rpm and 400 ft.-lb.+ of torque @ 4250 rpm (with premium fuel). The lightweight aluminum cylinder block features cross-bolted main bearing caps and thick main bearing bulkheads for bottom-end strength, optimized oil drainback and windage control to improve high-rpm performance.
  • 435 horsepower 400 ft.-lb.+ of torque
  • 11.0:1 Compression ratio
  • Hypereutectic aluminum pistons
  • Forged steel connecting rods
  • Forged steel crankshaft Aluminum block
  • 8qt capacity oil pan
  • Tuned composite intake manifold provides efficient air delivery and weight savings
  • 80 mm single bore "drive by wire" throttlebody with variable runner control
  • Aluminum cylinder heads, DOHC, four valves per cylinder, Variable intake and exhaust camshaft timing
  • Mustang GT 409 stainless-steel tubular exhaust manifold on the RIGHT SIDE ONLY
  • Includes manual transmission engine harness and flywheel Vehicle harness
  • Includes Ford Performance's NEW wiring, PCM and installation kit M-6017-504V designed for project car installation.
  • Does not include alternator, for alternator kit see M-8600-M50BALT
  • Engine mount bosses and bell housing mount pattern common to 4.6L modular engines
  • 5.0L Mustang engine cover kit available, see M-9680-M50A
  • Photo and specs may vary.
  • Engine weight: 444 lbs.
    • Engine Dimension PDF Chart CLICK HERE
Part Type
Engine: Complete Engines
Warranty Availability
Package Dimensions
36.5" x 64.5" x 36"
Package Weight
577.2 lb(s)
UPC Code
756122003466
Country of Origin
United States
